Product Introduction
NH2 column is based on propyl-amino silane, mostly used in normal phase, but can also be used in reversed phase.
Features
1. Used in normal phase for weak anion-exchange, and in reversed-phase HPLC for polar compounds.
2. For applications in aggressive normal phase mode with aqueous eluent.
3. Vitamins A and D can be separated in the normal-phase mode.
4. Carbohydrates and sugars can be separated in the reversed-phase mode.
Specifications
| pH Range | 2.0-8.0 |
| Particle Size | 3μm, 5μm, 10μm |
| Surface Area(m2/g) | 320(120Å) |
| Carbon Loading(%) | 4 (120Å) |
| USP List | L8 |
| Endcapped | No |
Ordering Information—NH2
| Particle Size | ID(mm) | Column Length (mm) | |||||||
| 30 | 50 | 75 | 100 | 150 | 200 | 250 | 300 | ||
3μm 120 Å | 2.1 | YZHNH2130-3 | YZHNH2150-3 | YZHNH2175-3 | YZHNH21100-3 | YZHNH21150-3 | YZHNH21200-3 | YZHNH21250-3 | - |
| 3.0 | YZHNH3030-3 | YZHNH3050-3 | YZHNH3075-3 | YZHNH30100-3 | YZHNH30150-3 | YZHNH30200-3 | YZHNH30250-3 | - | |
| 4.0 | YZHNH4030-3 | YZHNH4050-3 | YZHNH4075-3 | YZHNH40100-3 | YZHNH40150-3 | YZHNH40200-3 | YZHNH40250-3 | - | |
| 4.6 | YZHNH4630-3 | YZHNH4650-3 | YZHNH4675-3 | YZHNH46100-3 | YZHNH46150-3 | YZHNH46200-3 | YZHNH46250-3 | - | |
5μm 120 Å | 2.1 | YZHNH2130-5 | YZHNH2150-5 | YZHNH2175-5 | YZHNH21100-5 | YZHNH21150-5 | YZHNH21200-5 | YZHNH21250-5 | - |
| 3.0 | YZHNH3030-5 | YZHNH3050-5 | YZHNH3075-5 | YZHNH30100-5 | YZHNH30150-5 | YZHNH30200-5 | YZHNH30250-5 | - | |
| 4.0 | YZHNH4030-5 | YZHNH4050-5 | YZHNH4075-5 | YZHNH40100-5 | YZHNH40150-5 | YZHNH40200-5 | YZHNH40250-5 | - | |
| 4.6 | YZHNH4630-5 | YZHNH4650-5 | YZHNH4675-5 | YZHNH46100-5 | YZHNH46150-5 | YZHNH46200-5 | YZHNH46250-5 | - | |
10μm 120 Å | 4.0 | - | - | - | YZHNH40100-10 | YZHNH40150-10 | YZHNH40200-10 | YZHNH40250-10 | YZHNH40300-10 |
| 4.6 | - | - | - | YZHNH46100-10 | YZHNH46150-10 | YZHNH46200-10 | YZHNH46250-10 | YZHNH46300-10 | |
Don’t see your needed size or format? Please Contact Yicozoo.
