Product Introduction
SAX columns utilize a polarity-bonded packing material consisting of ammonium-functionalized silanes chemi-cally bonded to ultra-pure silica gel matrices, suitable for efficient anion exchange HPLC. Special applications include separation of carboxylic and sulfonic acids from several classes of organic acids such as aromatic and aliphatic. Specific application areas include pesticides, herbicides, pharmaceuticals, inorganic anions, and biological samples such as nucleotides and nucleosides.
Specifications
| pH Range | 2.0-8.0 |
| Particle Size | 3μm, 5μm, 10μm |
| Surface Area(m2/g) | 320(120Å), 90(300Å) |
| Carbon Loading(%) | 7.5(120Å), 1.5(300Å) |
| USP List | L14 |
| Endcapped | No |
Ordering Information—SAX
| Particle Size | ID(mm) | Column Length (mm) | ||||
| 50 | 100 | 150 | 200 | 250 | ||
3μm 120 Å | 2.1 | YZHSAX2150-3 | YZHSAX21100-3 | YZHSAX21150-3 | YZHSAX21200-3 | YZHSAX21250-3 |
| 3.0 | YZHSAX3050-3 | YZHSAX30100-3 | YZHSAX30150-3 | YZHSAX30200-3 | YZHSAX30250-3 | |
| 4.0 | YZHSAX4050-3 | YZHSAX40100-3 | YZHSAX40150-3 | YZHSAX40200-3 | YZHSAX40250-3 | |
| 4.6 | YZHSAX4650-3 | YZHSAX46100-3 | YZHSAX46150-3 | YZHSAX46200-3 | YZHSAX46250-3 | |
5μm 120 Å | 2.1 | YZHSAX2150-5 | YZHSAX21100-5 | YZHSAX21150-5 | YZHSAX21200-5 | YZHSAX21250-5 |
| 3.0 | YZHSAX3050-5 | YZHSAX30100-5 | YZHSAX30150-5 | YZHSAX30200-5 | YZHSAX30250-5 | |
| 4.0 | YZHSAX4050-5 | YZHSAX40100-5 | YZHSAX40150-5 | YZHSAX40200-5 | YZHSAX40250-5 | |
| 4.6 | YZHSAX4650-5 | YZHSAX46100-5 | YZHSAX46150-5 | YZHSAX46200-5 | YZHSAX46250-5 | |
10μm 120 Å | 4.6 | - | - | YZHSAX46150-10 | YZHSAX46200-10 | YZHSAX46250-10 |
